DAP-3662

Wireless AC1200 Dual-band Outdoor Gigabit PoE Access Point
(IP68, 2.4GHz: 300Mbps & 5GHz: 867Mbps; 6dBi internal antenna for 2.4GHz, 6dBi internal antenna for 5GHz, 802.3af PoE, PoE injector IS included)
Supports CWM (Central WiFiManager) & AP Array, H/W: A1

Technical Specifications

General

Device Interfaces
• 802.11a/g/n/ac wireless
• 2 Gigabit LAN Port (LAN1 supports PoE)

LEDs
• Power

Standards
• IEEE 802.11a/g/n/ac
• IEEE 802.3u/ab/af

Wireless Frequency Range
• 2.4 GHz band: 2.4 GHz to 2.4835 GHz
• 5 GHz band: 5.15 to 5.35 GHz, 5.47 to 5.85 GHz

Antennas
• Two internal 6 dBi for 2.4 GHz
• Two internal 6 dBi for 5 GHz

Maximum Output Power
• 26 dbm for 2.4GHz
• 26 dbm for 5GHz

Functionality

Security
• WPA-Personal
• WPA-Enterprise
• WPA2-Personal
• WPA2-Enterprise
• WEP 64/128-bit encryption
• SSID broadcast disable
• MAC address access control
• Network Access Protection (NAP)
• Internal RADIUS server

Network Management
• Telnet
• Secure Telnet (SSH)
• HTTP
• Secure HTTP (HTTPS)
• Traffic control
• SNMP
• D-Link Central WiFiManager
• AP Array

Physical/Environmental

Dimensions
• 10.91 x 9.45 x 1.97 inches (277 x 240 x 50 mm)

Weight
• 2.16 lbs (981 grams)

Operating Voltage
• 48 VDC +/- 10%, or 802.3af PoE

Maximum Power Consumption
• 12.5 Watts

Temperature
• Operating: -22 to 140 °F (-30 to 60 °C)
• Storage: -22 to 149 °F (-30 to 65 °C)

Humidity
• Operating: 10% to 90% non-condensing
• Storage: 5% to 95% non-condensing

Certifications
• FCC
• IC
• CE
• C-Tick
• UL
• Wi-Fi® Certified
• IP67

Warranty Information
• Limited Lifetime

Ordering Information
• DAP-3662      Wireless AC1200 Concurrent Dual Band Outdoor PoE Access Point
