Technical Specifications

General
Device Interfaces
• 802.11g/n wireless
• 1 Gigabit LAN port (supports 802.3af PoE)

LED
 • Power/Status

Standards
• IEEE 802.11b/g/n
• IEEE 802.3u/ab/af

Wireless Frequency Range
• 2.4 GHz band: 2.4 GHz to 2.4835 GHz

Antennas
• Two internal 3 dBi for 2.4 GHz

Maximum Output Power
• 26 dbm for 2.4GHz

Functionality

Security
• WPA-Personal
• WPA-Enterprise
• WPA2-Personal
• WPA2-Enterprise
• WEP 64/128-bit encryption
• SSID broadcast disable
• MAC address access control
• Network Access Protection (NAP)
• Internal RADIUS server

Network Management
• Telnet
• Secure Telnet (SSH)
• HTTP
• Secure HTTP (HTTPS)
• Traffic control
• SNMP
• AP Array

Physical and Environmental

Dimensions
• 6.69 x 6.69 x 1.1 inches (170 x 170 x 28 mm)

Weight
• 11.14 oz. (316 grams) with antennas

Operating Voltage
• 12 V DC +/- 10%, or 802.3af PoE

Maximum Power Consumption
• 8 Watts

Temperature
• Operating: 32 to 104 °F (0 to 40 °C)
• Storage: -4 to 149 °F (-20 to 65 °C)

Humidity
• Operating: 10% to 90% non-condensing
• Storage: 5% to 95% non-condensing

Certifications
• FCC
• IC
• CE
• Wi-Fi
• Certified

Warranty
• Limited Lifetime warranty

Ordering Information
• DAP-2330     Wireless N300 2.4GHz High Power Gigabit PoE Access Point
